| E-SYSTEM |
BOSCH PT-CX7K4 |
| FRAME |
Macina Lycan 27.5″ Alloy6061 SLL-E 140mm; PT750 Bosch Gen.4 / M-2296 |
| FORK |
FOX 34 Float AWL 27.5″ e-bike 140mm 15×110 |
| SHOCK |
FOX Float DPS Performance 230×62.5 |
| MOTOR |
Bosch PERFORMANCE CX Gen.4 SMART SYSTEM – 25km/h / 85Nm |
| DISPLAY |
Bosch LED remote SMART SYSTEM / Bosch KIOX 300 TFT Display SMART SYSTEM |
| BATTERY |
Bosch PowerTUBE 750Wh SMART SYSTEM hor. |
| CHARGER |
Bosch STANDARD Charger 4A SMART SYSTEM |
| R. DERAILL |
Shimano Deore XT M8100-12 SGS shadow+ |
| SHIFTLEV. |
Shimano Deore M6100-12 display |
| CRANKSET |
KTM E-TRAIL ISIS 170mm Q16 |
| CHAINRING |
FSA Megatooth steel 36T 12speed Direct Mount |
| SPROCKET |
Shimano Deore M6100-12 / 10-51 |
| CHAIN |
Shimano M6100-12 |
| BRAKE |
Shimano Deore M6100 / M6120 4-Piston |
| ROTOR |
Shimano RT64 CL 203 / 180 |
| WHEEL F |
KTM Line – Shimano MT410B CL 32H 110-15TA / Ambrosio E30 Trail 32H 584x30TC / DT Champion 2.0 black |
| WHEEL R |
KTM Line – Shimano MT410B CL 32H 148-12TA / Ambrosio E30 Trail 32H 584x30TC / DT Alpine II 2.34 black |
| TIRE F |
Schwalbe Nobby Nic Perf. Folding 65-584 |
| TIRE R |
Schwalbe Nobby Nic Perf. Folding 65-584 |
| GRIP |
Ergon GA20 |
| BAR |
KTM COMP II Trail35 rizer15 760mm |
| STEM |
KTM TEAM II Trail35 |
| HEADSET |
Acros AICR internal 1.1/8″-1.5″ angle limit |
| SADDLE |
Selle San Marco Ground Short Open Fit Narrow |
| SEATPOST |
KTM COMP II dropper internal |
| PEDAL |
MTB-Pedal flat VPE-527 alloy |
| WEIGHT |
26,60 kg |
| PERMISSIBLE TOTAL WEIGHT |
146 kg |
